Which MarkMate® Fits Your Parts?
MSI builds three MarkMate® machines for round parts. Pick by where the mark goes (the end of the part or around its outside diameter), the size of the part, and whether an operator or a FeedMate® feeder does the loading.
MM-24 MarkMate®: End Marking, Operator Loaded
The MM-24 marks the ends of shafts, bolts, studs, and similar parts. Its small footprint and easy diameter and length changeover make it a good fit for marking parts as they are cut on band saws.
- Parts 1/2 in. to 3 in. diameter and 2 in. to 24 in. long
- 10,000 lb of marking force at 100 psi air line pressure, adjustable with air pressure regulation
- Marks one or both ends of a part
- Uses 1/2 in. round x 1 in. long marking inserts, or custom inserts
- 21 in. x 39 in. floor space, with dual palm valves for safety
AMM-24 AutoMarkMate®: End Marking with Automatic Feeding
The AMM-24 is the auto-feeding version of the MM-24, built for marking the ends of studs, rods, and shafts at higher production rates.
- Parts 1/2 in. to 1-1/2 in. diameter and 2 in. to 24 in. long
- Up to 40 parts per minute
- 10,000 lb of marking pressure at 100 psi air line pressure
- Hand loaded, or fitted with a FeedMate® parts feeder for fully automated marking
- Designs for blank or threaded parts
Rotary MarkMate®: Marking Around the Outside Diameter
The Rotary MarkMate® marks the outer diameter of cylindrical parts such as pipe nipples.
- 1/2 in. to 4 in. OD, with lengths up to 12 in.
- Up to 40 parts per minute with a chain feed
- Hand fed, or attached to a FeedMate® step feeder for a fully automated system
- Type holder included
Chamfer and Mark on One Machine
If the same bolts and studs also need a chamfer, the C3A-M ChamferMate® chamfers and stamps parts from 3/8 in. to 3 in. in diameter in one process.
How to Choose
End marks on parts larger than 1-1/2 in. in diameter, up to 3 in., go on the MM-24. For end marks on parts from 1/2 in. to 1-1/2 in. at volume, the AMM-24 runs up to 40 parts per minute and can be paired with a FeedMate® feeder. Marks around the outside of a part, such as pipe nipples, call for the Rotary MarkMate®.
